Air Flow Visualization Study

It is the best when studying airflow in cleanrooms, barrier systems, and controlled settings with Ziebaq. Using our special "Tracer Particle Visualization" methods, our experts do airflow visualisation studies showing how air actually flows. We are experts at doing the right paperwork to meet the requirements of regulators like the FDA and the EU for in-situ air pattern analysis studies. The way we study airflow imaging is unique. Ziebaq's experts can also help use these studies to create risk-based environmental monitoring (EM) programs by advising on choosing EM sample sites based on the data gathered during the airflow visualisation.

Our airflow visualisation strategy

• We use our own tools
• A tracer particle with the right stability and lifetime to accurately show how air flows in real-life
• Using more than one camera to record the dangers of eddy currents and weird wind patterns
• Use of particle measurement and smoke study together to find monitoring's most important control points
• Simulations of setting up and putting together equipment, aseptic connections, activities, and the moving of parts and products, as well as changes to the surroundings to see how they affect real airflow patterns
• Please find out how the environment around vital places affects them
• Expert advice on how to document proof of wind patterns

Advantages of this airflow visualisation method

• Find problems with blocking technology or important environment design
• Avoid environmental monitoring trips, media filling, and product failures by finding eddy currents and irregular airflow patterns that can be fixed and closely watched to lower risk
• Finding and fixing badly planned, built, managed, and connected cleanrooms and barrier systems will help keep data safe
• Check to see if the gowning strategies and practices used are enough to support operations, along with the design and integration of the building and barrier system
• Look at how aseptic methods and changes affect airflow patterns

Check out our Airflow Visualization Service!

Ziebaq can do airflow visualisations for your facility to confirm design and performance specifications, help find faults in areas with high levels of contamination, and see what happens when an operator messes with one-way airflow in controlled environment enclosures. They offer a full end-to-end service for maintaining, testing, and verifying your specialist ventilation system.

We will put custom-made sparge lines in the right places around your clean room to spread pharmaceutical-grade smoke (Glycerine BP grade and pure water). We will digitally record the airflow patterns and include an information board with a unique test ID. When needed, walls and floors are given a black background to make the smoke stand out.

You download this video to a portable recording device while the tests are happening so that you can watch it immediately, analyse it, and get approval from your quality department. Your test procedure can then include saving it to a DVD, and you can get a full test report with certification, a qualitative review, and suggestions.
